PRODUCT SPECIFICATION OF FF1108-1:

1) Display: 2inch TN/ANTI-UV LCD

2) Depth Capability: 328feet(100m)

3) Power Requirement: 4xAAA alkaline batteries(not included)

4) Waterproof design: level-4 (spray-water-proof)

5) Show water depth, fish location, and bottom grass & rock

6) User selectable sensitivity,depth units, and fish alarm setting

7) Operational Temperature: 14°F to 122°F(-10°C to 50°C)

The function of 1108-1 is Anti-clutter、ice probe、water depth、Fish icon、wide detection and turbid water detect

Please put the cable transducer in fishing spot

The monitor displays information from sonar sensors that detect water and fish

The transducer can detect water up to 100m,45degree beam angle in 200khz

1108-1 underwater detection 100M

1.Sensitivity indicator

2.Battery save on/off
3.Fish alarm on/off
4.Set up key
5.Battery strength indicator
6.Water depth indicator
7.Backlight on/off
8.Fish depth indicator
9.Enter key
10.Power On/Off

1.Float
2.Transducer
3.Cable

PRODUCT SPECIFICATION OF FFW1108-1:

1) Display: 2inch TN/ANTI-UV LCD

2) Depth Capability: 130feet(40m)

3) Wireless Sonar: 90 degrees beam angle in 125Khz

4) Wireless operational Range: 400feet(120m)

5) Power Requirement: 4xAAA alkaline batteries(not included)

6) Wireless Sensor battery reauirement: one replaceable CR2032 battery

7) Waterproof design: level-4 (spray-water-proof)

8) Show water depth, fish location, and bottom grass & rock

9) User selectable sensitivity , depth units, and fish alarm setting

10) Wireless Sensor could shut down when it is out of the water

11) Operational Temperature: 14°F to 122°F(-10°C to 50°C)

The wireless sensor cananti-clutter system automatically filter clutter.

1108-1 has fish alarm.

The sonar can detect water up to 100m,90degree beam angle in 125khz.

The sonar can detect water up to 40m and wireless range is 120m.

How to use Lucky fish finder?

1.Tie it to the end of fishing line and cast it into the water

2.wireless sonar sensor send sound waves

3.returned echoes transmitted to the fish finder
